The tiered 2×2 Bike Rack is a versatile, all-steel solution for storing or displaying bikes in garages, homes, bike shops, and other spaces. Its height-adjustable design helps maximize space while keeping bikes organized and accessible. With 21" spacing between bikes and your choice of Regular or Fat Tire trays, it accommodates a wide range of acoustic and electric bikes.
The 2×2 supports e-bikes on both tiers, although we recommend placing the heaviest bikes on the bottom tier for added stability and easier loading. Configure trays in the same or alternating directions to suit your space. Optional lockable casters provide added mobility.
- Regular Trays: tires up to 2.75" wide
- Fat Tire Trays: tires from 2.5" to 5.0" wide
- Load Limit: 80 pounds per tray
Made in the USA
Couldn't load pickup availability
Dimensions
Dimensions
| Tray Option | Format | Dimensions (Length x Depth x Height*) |
|---|---|---|
| Regular Trays | Single Direction | 36” Length x 72” Depth x 64 to 70” adjustable Height |
| Regular Trays | Alternate Directions | 36” Length x 85” Depth x 64 to 70” adjustable Height |
| Fat Trays | Single Direction | 36” Length x 75” Depth x 65 to 71” adjustable Height |
| Fat Trays | Alternate Directions | 36” Length x 88” Depth x 65 to 71” adjustable Height |
*Caster wheels will add 4″ to the height.
Weight Capacity
80 lbs. per tray
Assembly Instructions
Assembly Instructions
